Bi-metallic Lugs
Bi Metallic Lugs
Bi-metallic Lugs
Bi Metallic Lugs

Bi-Metallic Terminals

Key Features & Benefits:



  • Material: Aluminium barrel + copper palm, friction-welded
  • Corrosion Resistance: Prevents electrolytic reaction between Al/Cu
  • Finish: Tin-plated for improved conductivity and oxidation resistance
  • Mechanical Strength: Deep barrel ensures secure crimping
  • Sizes Available: 16mm² to 630mm²
  • Extends service life of electrical connections
  • Reduces resistance and heat at connection points
  • Provides a professional and safe termination method
  • Compatible with hydraulic or mechanical crimping tools

Available from stock on short lead times

Manufactured using 99.5% minimum copper content

For use with flexible cables please call and speak to our sales team.

Bi Metallic Terminals

Bi-metallic Terminals or lugs are specially designed connectors used for joining aluminium cables to copper busbars, terminals, or equipment. They combine a high-conductivity aluminium barrel with a copper palm, permanently friction-welded together to create a strong and corrosion-resistant joint. This prevents galvanic reaction between dissimilar metals, ensuring a safe, long-lasting electrical connection. These lugs provide a safe, permanent connection in power distribution, switchgear, control panels, and industrial installations. Manufactured to meet IEC/BS standards.

Applications



    • LV and MV power cable terminations
    • Switchgear, transformers, and distribution boards
    • Industrial control panels and power supply equipment
    • Renewable energy systems (solar, wind, battery storage)
    • Anywhere aluminium conductors must connect to copper busbars

We would recommend using an indent crimper as Aluminium is a softer metal then Copper.

For use with flexible cables please call and speak to our sales team.

Bi Metallic Lug Range

Part Number Cable Entry (mm) Hole Size (mm) Barrel ID (mm) Barrel OD (mm) Length (mm) Barrel Depth (Internal) (mm)
BIMET16M12 16 13 6 16 90 42
BIMET25M12 25 13 7 16 90 42
BIMET35M12 35 13 8.5 16 90 42
BIMET50M12 50 13 9.6 20 90 43
BIMET70M12 70 13 11.5 20 90 43
BIMET95M12 95 13 13.5 20 91 43
BIMET120M12 120 13 15 25 115 60
BIMET150M12 150 13 16.6 25 115 60
BIMET185M12 185 13 18.5 32 122 60
BIMET240M12 240 13 21 32 122 60
BIMET300M12 300 13 23 34 122 60
BIMET400M16 400 17 28 40 164 94
BIMET500M16 500 17 30 40 164 88
BIMET630M16 630 17 34 47 183 100
